Product Description
- Developed and manufactured in-house by LALIZAS for optimal performance and reliability
- For ship-to-ship or ship-to-shore line deployments, water rescues etc.
- Equipped with 4 rope prefilled projectiles and capable of firing each projectile over 230 m, complying with the requirements of Resolution MSC. 48(66) (LSA Code)
- The projectile is ejected from the thrust created by the instant release of compressed air from the air cylinder, making it safe for use even in flammable areas.
- A fully charged air cylinder (200 bar) can supply up to 4 maximum-range shots for the LALIZAS PLT device
- Aerodynamic projectile shape ensures minimum wind effect during operation
- SOLAS/MED/USCG approved
- Complies with Resolution MSC.81 (70) as amended
VALUE FOR USER
- Operated by compressed air instead of pyrotechnics facilitating transportation and storage globally
- The air cylinder is fully compatible with any 200 bar refill station for breathing air systems, provided the correct DIN 200 bar adapter is used
- The rechargeable compressed air cylinder allows for crew training with minimal to no material costs
- Significant economic benefit through lower long-term operational cost (no expiration date, minimised maintenance)
- Availability of spare parts:
- Projectile Assembly for LALIZAS Pneumatic Line Throwing Device (75454)
- Air Cylinder Assembly for LALIZAS Pneumatic Line Throwing Device (75455)
Items / Versions
| Code | Description | Volume | Material | Bag Size | Total Bag Weight | Finish | Minimum Shots | Shooting Chamber Pressure | Cylinder | Air Pressure |
|---|---|---|---|---|---|---|---|---|---|---|
| 75295 | LALIZAS Pneumatic Line Throwing Device, SOLAS/MED/USCG, Set | 2 L | Aluminum, Stainless Steel, POM, ABS | 810 x 765 x 225 mm | 17 kg | Hard Anodised | 4 projectiles | approx. 80Bar | Steel | 200 bar |
